Sharp Signage Display
Sharp MultiSync® E759
The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer.
- Reduced Installation and Operating Costs – highly energy efficient LED backlit display ensures low power consumption, longer backlight lifetime and lighter design for easy transportation, mounting and integration.
- Slim Design and Integrated Speakers – the aesthetic design is pleasing to the eye and enables easy, low cost installation.
- Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
- Standalone operation – the display is designed for straightforward standalone operation due to integrated USB media player, speakers and scheduling functionality.
Connettività e compatibilità
-
NaViSet Administrator è una piattaforma software di gestione e monitoraggio remoto per display, proiettori e dispositivi correlati NEC e Sharp
-
USB Type‑C è un piccolo connettore utilizzato per il trasferimento dei dati, il caricamento, la trasmissione audio e video in un singolo cavo
-
Questo prodotto supporta la risoluzione 4K.
Panoramica
Professional performance, affordable value The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels. Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the...
Specifiche tecniche
| Generalità | |
|---|---|
| Weight (kg) | 24 |
| Panel Data | |
|---|---|
| Dimensione lunetta (S/D) mm | 13 |
| Dimensione lunetta (A/B) mm | 13 |
| Tempo di risposta (media grigio su grigio) ms | 8 |
| Installation | |
|---|---|
| Verticale | SÌ |
| Orizzontale | SÌ |
| Orizzontale | SÌ |
| Verticale | SÌ |
| Montaggio (VESA/Numero di punti/picco mm) | 600 x 400 (FDMI) |
| Montaggio (VESA/Numero di punti/picco mm) | 4 |
| Specifiche delle viti d montaggio (dimensioni/lunghezza massima) | M8 |
| Display Module Data | |
|---|---|
| Risoluzione nativa (Pixel) | 3840 x 2160 |
| Luminosità (cd/m2) | 350 |
| Picco pixel (mm H/V) | 0.43 |
| Colour Depth [bn] | 1.07 (8bit + FRC) |
| Area schermo attiva(H/V) mm | 1650.2 x 928.3 |
| Response Time (typ.) [ms] | 8 |
| Key Specifications | |
|---|---|
| Altoparlanti incorporati (W) | 10 + 10 |
| Operating Time | 16/7 |
| Power Supply and Operating Environment | |
|---|---|
| Tensione operativa (ACV) / Frequenza (Hz) | 100-240 |
| Tensione operativa (ACV) / Frequenza (Hz) | 50-60 |
| Tramite Caricatore AC | SÌ |
| Tensione operativa (DCV) | 100-240 |
| Consumo di corrente (W) (funzionamento MASSIMO) | 170 |
| Temperatura operativa (oC) | 0 - 40 |
| Storage Temperature [°C] | -20 - 60 |
| Storage Humidity [%] | 10 |
| Storage Humidity [%] | 80 |
| Power Saving Mode (W) | < 2 (Networked Standby) |
| Weights and Measures | |
|---|---|
| Dimensioni del cartone dell'imballaggio (L/A/S) mm | 1875 |
| Dimensioni del cartone dell'imballaggio (L/A/S) mm | 1130 |
| Dimensioni del cartone dell'imballaggio (L/A/S) mm | 186 |
| Peso dell'imballaggio (Kg) | 33 |
| Image | |
|---|---|
| Aspect Ratio | 16:9 |
| Contrast Ratio | |
| Display | |
|---|---|
| Haze Level (%) | Pro (25) |
| Panel Technology | IPS with Direct LED backlights |
| Screen Size (inch) | 75 |
| Screen Size (cm) | 189 |
| Viewing Angle | |
| Resolution | |
|---|---|
| Supported Resolution | 1024 x 768 , 1920 x 1200, 1400 x 1050, 720 x 480, 720 x 400, 720 x 576, 1360 x 768, 3840 x 2160, 4096 x 2160, 1680 x 1050, 1280 x 960, 1280 x 720, 640 x 480, 1920 x 1080, 1280 x 1024, 1440 x 900, 1280 x 800 |
| Synchronisation Rate | |
|---|---|
| Horizontal Frequency [kHz] | 31.5 - 135 |
| Vertical Frequency [Hz] | 24 - 75 |
| Connectivity | |
|---|---|
| Output / Control | LAN 100Mbit |
| Digital | HDMI, USB Type C |
| Electrical | |
|---|---|
| Power Supply | |
| Consumo di corrente in attivazione (IEC62087:2012) | 170 (shipping) |
| Mechanical | |
|---|---|
| Dimensione lunetta (S/D) mm | 13 |
| Dimensione lunetta (A) mm | 13 |
| Dimensione lunetta (B) mm | 13 |
| Environmental Conditions | |
|---|---|
| Operating Humidity (min) [%] | 20 |
| Operating Humidity (max) [%] | 80 |
| Ergonomics | |
|---|---|
| Landscape Dimensions (Width) [mm] | 1680 |
| Landscape Dimensions (Height) [mm] | 959 |
| Landscape Dimensions (Depth) [mm] | 59 |
| MediaPlayer | |
|---|---|
| Supported Image Formats | |
| Regulatory | |
|---|---|
| Safety and Ergonomics | UKCA, CE, VCCI, RCM |
| Green Features | |
|---|---|
| Ecological Standards | Energy Star 8.0 |
| Energy Efficiency | Energy consumption: 155 kWh/1000 h, LED backlight technology, Energy efficiency class: G |
| Supplied Accessories | |
|---|---|
| Shipping Content | Power Cable, Remote Control, 2 x AAA batteries, Setup Manual, Display |
| Additional Features | |
|---|---|
| Colour Versions | Black Back Cabinet, Black Front Bezel |
| Accessories | |
| Special Characteristics | |
| Remote Management | |
| Warranty | 3 years warranty incl. backlight |
